Gap Bed Lathe Machine GH1860ZX
Request a Quote
Availability: 0–30 days
Delivery: 0–30 days
Features:
1.3-1/8”bore spindle is supported by two tapered and one ball bearings
2.Chromemoly bdenum headstock gears are hardened, ground and shaved Universal gearbox allows inch, metric, diametral and module pitch threads, no change gears required
3.Carriage features one-shot lubrication and Turcite-B on bed sliding surfaces
4.T-slotted compound slide featuring four-way tool post
5.One piececast iron base absorbs vibration allowing heavier cuts
6.High quality ANSI Class 50 wear resistant cast iron bed ways are hardened and ground
7.Removable gap allows large diameter work
8.Five position automatic carriage stop increases productivity
9.Attractive chrome levers, dials and knobs complete this impressive package
Meehanite Castings
Need pricing or bulk? Request a quote
Nationwide
Delivery
Delivery
PayPal & Cards
100% Genuine
Products
Products
Genuine & Warranted
Sourced from trusted suppliers with manufacturer-backed warranty.
Fast Nationwide Delivery
Availability 0–30 days, then delivery within 0–30 days anywhere in Kenya — items in stock in Nairobi dispatch same day.
Expert Support
Talk to our team on WhatsApp for specs, quotes and bulk orders.
Product Description
| MODEL | 1880ZX | 1860ZX | 1840ZX | 1660ZX | 1640ZX | 1460XZ | 1440ZX | |||
| Max. swing over bed | mm | Φ460(18") | Φ410(16") | Φ360(14") | ||||||
| Max. swing over carriage | mm | Φ290(10-4/5") | Φ250(10") | Φ200(7-2/3") | ||||||
| * Max. swing over gap | mm | Φ700(27-1/2") | Φ660(26") | Φ600(23-5/8") | ||||||
| *Max. length of work piece(two centers) | mm | 2000(80”) 1500(60”) 1000(40”) 1500(60”) | 1500(60”) | 1000(40”) | 1500(60”) | 1000(40”) | ||||
| *Effective length of gap | mm | 200(8") | ||||||||
| Spindle nose | mm | Φ80(3-1/8") | ||||||||
| Spindle taper of bore | / | M.T.No.7 | ||||||||
| Number of speeds | / | 12 | ||||||||
| Range of speeds | rpm | 42~1800 or 25~1800 | 42~1800 or 25~1800 | 42~1800 | ||||||
| Thread cutting for Metric pitch threads | Range/No. | 0.5~20mm/24 | ||||||||
| Thread cutting for Whit-worth pitch threads | Range/No. | 72~1-5/8 t.p.i/61 | ||||||||
| Thread cutting for Module threads | Range/No. | 96~3-1/4 D.P/45 | ||||||||
| Thread cutting for D.P. threads | Range/No. | 0.25~10 M.P/20 | ||||||||
| Range of feeds for longitudinal | mm | 0.04~2.46(0.0015"-0.0913") | ||||||||
| Range of feeds for cross | mm | 0.02~1.23(0.005"-0.0365") | ||||||||
| Tailstock sleeve dia. | mm | Φ75(3") | ||||||||
| Tailstock taper of bore | mm | M.T.No.5 | M.T.No.4 | |||||||
| Tailstock sleeve max. travel | mm | 130(5") | ||||||||
| Max. travel of compound rest | mm | 100(4") | ||||||||
| Max. cross slide travel | mm | 280 (11") | ||||||||
| Max. size of tool shank(WxH) | mm | 25×25(1”×1") | ||||||||
| Power of main motor | kw | 5.5 | ||||||||
| Overall dimensions(L×W×H) | mm | 3320x1000x 1295 | 2810x1000x 1295 | 2310x1000x 1255 | 2810x1000x 1275 | 2310x1100x 1275 | 2810x1000x 1255 | 2310x1100x 1255 | ||
| Net weight | kg | 2900 | 2650 | 2350 | 2600 | 2300 | 2550 | 2250 | ||
